Vancouver
10199 Original price 14499
Next-generation Advanced composite mainframe and rear swingarm is 250g lighter than previous version. The bottom bracket area is stiffer for faster acceleration, and a steeper seattube puts the rider in an efficient, front-forward climbing position.
All-new FlexPoint Pro suspension delivers 100mm of smooth, active rear travel. The reengineered frameset features modern XC geometry including a slacker 67.5-degree headtube and 110mm suspension fork for technical descents.
Frame geometry and suspension are optimized for larger-diameter 29-inch wheels. A longer reach and updated cockpit including a 35mm composite handlebar and alloy stem further boost balance and stability on XC terrain.
Engineered with a full composite frameset, this 29er has 100mm of rear suspension travel and 110mm up front. The linkage-driven, single-pivot FlexPoint Pro rear suspension makes room for shorter chainstays to improve climbing capabilities and overall agility. Other updates include new 29er-specific XC race geometry with a longer reach and a slacker headtube angle plus a lightweight, stiff composite wheelset for quick, precise handling.
Giant’s High Performance Grade raw carbon material is used to produce this custom frame material in our own composite factory with a high stiffness-to-weight ratio. The front triangle of these framesets is assembled and molded as one continuous piece in a proprietary manufacturing process called Modified Monocoque Construction.
A state-of-the-art high-pressure molding process is used to produce complex-shaped carbon fiber components that are lighter, stiffer and stronger than similar components made from aluminum. This technology is used in critical performance parts such as Maestro Suspension rocker links.
Giant’s original oversized fork steerer tube technology. Designed to provide precise front-end steering performance, the system’s oversized headset bearings (1 1/4” lower and 1 1/8” upper for road, 1 1/2” lower and 1 1/8” upper for mountain) and tapered steerer tube work in conjunction to provide optimal steering stiffness.
Fewer flat tires. Greater traction. Less rolling resistance and a smoother, faster ride. Giant’s Tubeless System makes it easier than ever to experience all these benefits.
Developed as a superlight rear suspension setup for XC bikes that demand efficiency, control and responsive handling, FlexPoint Pro is a linkage-driven, single-pivot system that delivers 100mm of rear-wheel travel. It’s engineered with a full-composite swingarm that significantly reduces overall frame weight.
Sizing to be used as a reference only. Please check with a local authorized dealer to determine the correct size.
Available sizes may vary from country to country.
180 cm5’11” 188 cm6’2”
| M | L | ||
|---|---|---|---|
| A | Seat Tube Length (mm) (inch) | 42016.5 | 46518.3 |
| B | Seat Tube Angle (degrees) | 75.5° | 75.5° |
| C | Top Tube Length (mm) (inch) | 60423.8 | 62624.6 |
| D | Head Tube Length (mm) (inch) | 953.7 | 1054.1 |
| E | Head Tube Angle (degrees) | 67.5° | 67.5° |
| F | Fork Rake (mm) (inch) | 441.7 | 441.7 |
| G | Trail (mm) (inch) | 1094.3 | 1094.3 |
| H | Wheelbase (mm) (inch) | 115945.6 | 118346.6 |
| I | Chain Stay Length (mm) (inch) | 43517.1 | 43517.1 |
| J | Bottom Bracket Drop (mm) (inch) | 421.7 | 421.7 |
| K | Stack (mm) (inch) | 59323.3 | 60323.7 |
| L | Reach (mm) (inch) | 45017.7 | 47018.5 |
| M | Stand Over Height (mm) (inch) | 75029.5 | 77730.6 |
| N | Handlebar Width (mm) (inch) | 76029.9 | 76029.9 |
| O | Stem Length (mm) (inch) | 702.8 | 702.8 |
| P | Crank Length (mm) (inch) | 1756.9 | 1756.9 |
| Q | Wheel Size | 29" | 29" |
All prices and specifications are subject to change without notice.
