Trance Advanced
Pro 29 0

$13,499

What is my size?

Item # {{ partnumber.code }}

{{partnumber.supplementaryGroup.introText}} {{partnumber.supplementaryGroup.urlLabel}}

{{partnumbersByColor()[0].description}}{{partnumbersByColor()[0].globalFrameSize}}

{{partnumbersByColor()[0].priceToFormat}}

{{partnumbersByColor()[0].stock.Label}}

Ships from warehouse and will be available for pick-up in about 10-12 business days
(Does not apply to gear items. Gear orders are shipped directly to consumer).
Shipping costs: {{partnumber.shippingCosts}}

Expected in our warehouse around {{partnumber.stock.DateExpectedToFormat}}  and shipped in about 1 week{{partnumber.stock.DateExpectedToWeeks}}-{{partnumber.stock.DateExpectedToWeeks + 1}} weeks

Our Canadian warehouses will be closed for the Holiday season beginning December 12th 2022 through till January 3rd 2023. While we're away, your friendly neighborhood bike shop is ready to help! Nos entrepôts seront fermés pour la période des fêtes du 12 décembre 2022 au 3 janvier 2023. Pendant notre absence, votre magasin de vélos de quartier est là pour vous aider!

Share

Shred hard and shred fast with this lively 29er. It’s built on an all-new full-composite frame with adjustable geometry, giving you smooth control to blitz technical trails at speed.

Key Performance Factors

Adjustable frame geometry

New flip chip feature lets you change the head tube and seat tube angles, as well as the bottom bracket height, to fine-tune handling for varying trail conditions and individual riding style.

29er confidence and control

Larger 29-inch diameter wheels optimized to roll over rough terrain with balance and stability, giving you the momentum to tackle technical climbs and the confidence to fly on fast, rugged singletrack descents.

Progressive trail design

Lightweight Advanced-grade composite frameset features a longer reach and steeper seat tube for aggressive trail riding and improved climbing capabilities. Updated Maestro rear suspension features 120mm of rear wheel travel paired with a 130mm fork up front.

Highlights

This versatile trail bike features a full composite frame fitted with a new Maestro suspension system that offers 5mm more travel than the previous generation. The Advanced Forged Composite rocker arm has a flip chip that allows you to adjust frame geometry. Choose steeper or slacker head tube and seat tube angles and either a 35mm or 45mm bottom bracket drop to adjust the handling for your riding style and terrain.

Trance Advanced Pro 29 with interactive tooltips

Techs & Features

Advanced Composite Technology
Advanced Forged Composite Technology
Maestro Suspension Technology
OverDrive
Tubeless System
Flip Chip - Maestro
PowerCore

Sizing Guide and Geometry

Sizing to be used as a reference only. Please check with a local authorized dealer to determine the correct size.
Available sizes may vary from country to country.

Selection of a button will change the units measurement displayed throughout the entire sizing guide section.
  • S
      163 cm5’4”  to 172 cm5’8”
  • M
      171 cm5’7”  to 180 cm5’11”
  • L
      179 cm5’10”  to 188 cm6’2”
  • XL
      187 cm6’2”  to 198 cm6’6”
bike diagram with measurements referenced in table that follows
Selection of a button will change the units measurement displayed throughout the entire sizing guide section.
  SMLXL
  LOW | HIGHLOW | HIGHLOW | HIGHLOW | HIGH
ASeat Tube Length (mm) (inch)42016.543016.946518.349619.5
BSeat Tube Angle (degrees)77.2° | 78.0°76.3° | 77.0°76.3° | 77.0°76.3° | 77.0°
CTop Tube Length (mm) (inch)56122.1 | 5592259923.6 | 59723.562624.6 | 62424.666326.1 | 66126
DHead Tube Length (mm) (inch)1003.91104.31204.71305.1
EHead Tube Angle (degrees)65.4° | 66.2°65.5° | 66.2°65.5° | 66.2°65.5° | 66.2°
FFork Rake (mm) (inch)441.7441.7441.7441.7
GTrail (mm) (inch)1265 | 1204.71265 | 1204.71265 | 1204.71265 | 1204.7
HWheelbase (mm) (inch)116645.9 | 116545.9119547 | 119447122448.2 | 122348.1126349.7 | 126249.7
IChain Stay Length (mm) (inch)43917.3 | 43717.243917.3 | 43717.243917.3 | 43717.243917.3 | 43717.2
JBottom Bracket Drop (mm) (inch)451.8 | 351.4451.8 | 351.4451.8 | 351.4451.8 | 351.4
KStack (mm) (inch)61024 | 60423.861924.4 | 61324.162824.7 | 62224.563725.1 | 63124.8
LReach (mm) (inch)42216.6 | 43016.944717.6 | 45517.947218.6 | 48018.950720 | 51520.3
MStand Over Height (mm) (inch)72928.7 | 7372972328.5 | 73228.874629.4 | 75529.775129.6 | 76029.9
NHandlebar Width (mm) (inch)78030.778030.778030.778030.7
OStem Length (mm) (inch)401.6401.6502502
PCrank Length (mm) (inch)1656.51706.71706.71706.7
QWheel Size 29"29"29"29"
Specs
  • Sizes
    S, M, L, XL
  • Colours
    Pulp Gray / Terracotta / Black Chrome
  • Frame
    Advanced-Grade Composite front and rear triangles, 120mm Maestro suspension, flip chip, 12x148mm thru-axle
  • Fork
    Fox 34 Factory, 130mm, GRIP 2 damper, Boost 15x110 Kabolt, 44mm offset, custom tuned for Giant
  • Shock
    Fox Float X Factory, lockout, 185/50, custom tuned for Giant
  • Handlebar
    Giant Contact SLR Trail Integrated, Advanced Composite, 5-position adjustable, 800mm (760mm minimum cut width), 7/8/9° Back Sweep adjust system, meets DH test standard, GPS mount included
  • Grips
    Giant Tactal Pro Single S:120mm, M:120mm, L:130mm, XL:130mm
  • Stem
    Giant Contact SLR Trail Integrated, Advanced Composite, 5-position adjustable, 40/45/50mm Reach, +3°/0°/-3° Adjust System
  • Seatpost
    TranzX travel-adjustable dropper, remote S: 120-150mm travel / 30.9 x 459mm M: 140-170mm travel / 30.9 x 499mm L: 170-200mm travel / 30.9 x 525mm XL: 170-200mm travel / 30.9 x 525mm
  • Saddle
    Giant Romero SL
  • Pedals
    N/A
  • Shifters
    SRAM XX1 Eagle AXS Rocker Paddle, 1x12
  • Front Derailleur
    N/A
  • Rear Derailleur
    SRAM XX1 Eagle AXS
  • Brakes
    Shimano XTR BR-MT9120, hydraulic, Shimano RT-66 rotors [F]180mm, [R]180mm
  • Brake Levers
    Shimano XTR BL-M9120
  • Cassette
    SRAM XG 1295, 12-52
  • Chain
    SRAM X01 Eagle
  • Crankset
    SRAM XX1 Eagle DUB SL, 30t S:165mm, M:170mm, L:170mm, XL:170mm
  • Bottom Bracket
    SRAM DUB, press fit
  • Rims
    Zipp 3ZERO MOTO 29 carbon
  • Hubs
    Zipp 3ZERO MOTO 29 carbon
  • Spokes
    Zipp 3ZERO MOTO 29 carbon
  • Tires
    [F] Maxxis Minion DHF 29x2.5 WT, 3C MaxxTerra, EXO, TR [R] Maxxis Aggressor 29x2.5, EXO, TR, tubeless
  • Extras
    tubeless prepared, 2.6" max tire size, 34t max chainring size, MRP V3 Carbon chain guide
  • Weight
    The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.

All prices and specifications are subject to change without notice.
